Beautiful, Fast, Responsive & Wonderfully Compliant. The Excel Is Precision Engineered For The Ride Of Your Life

  • Frame MaterialCustom made 6Al 4V titanium
  • Frame Finish Included Satin Bead with either Anodised or Mirror Logos
  • Axles (Disc) 12mm x 100mm Front, 12 x 142mm Bolt Thru
  • Axles (Rim) 9mm x 100mm Front, 9 x 130mm Rear QR
  • Bottom Bracket (Disc) T47 68mm | (Rim) BSA 68mm
  • Brake Mount (Disc) Flat Mount, 140 or 160mm Rotor
  • Brake Mount (Rim) Standard single bolt road caliper brake
  • Seat Tube Internal 31.6mm or 27.2 with a shim
  • Seat Tube External 34.9mm
  • Headset Integrated ZS44 Upper / EC44 Lower (Chris King Inset 7/8)
  • Tyre Clearance (Disc) 700c x 32mm
  • Tyre Clearance (Rim) 700c x 28mm
  • Front Derailleur 34.9mm Band On

Having a frame that fits you perfectly is a critical part of the process. We have over 20 years of bike fitting experience and data to call upon to ensure your riding position is absolute pinpoint. Our set frame sizes at 1cm increments will work very well for the majority of people but there is also a full custom geometry option (extra charge) should the set size not work for you.

Please see our sizing / geometry page

Each Excel is handmade to order in our Sussex workshop which gives us complete control over the whole process from start to finish. This means every frame can be tuned to the riders’ specific needs, whether it be custom frame geometry, tyre clearance, cable routing, eyelets, frame finish and more. For full bike purchases almost any specification is possible so if you have something in mind for your new bike build, just let us know and we can make it happen.

If you purchase a complete bike, it will be supplied fully assembled although a small amount of assembly may be required if the bike is shipped via a courier service. We can build a bike using components supplied by customers, please get in touch to discuss options and prices.

To get started call, email or book a workshop visit online via our website. We will discuss your riding style, your objectives and targets as well as considering any existing bike fitting data that you may have. This information will enable us to create a precise picture of just what you are looking for.

Alternatively speak to one of our chosen cycle retail partners to guide you through the process, all carefully selected for the expertise, facilities and service they provide

Once the design and specification are complete and signed off, we will request a deposit of £1000 to hold your production slot. Once the deposit has been made, your bike will then be added to our workshop build list. It’s at this point that we will collate all of your chosen build parts for assembly.

Please note, if you’re intending to pay through a cycle scheme then your deposit will be refunded once we’ve processed your voucher, normally upon handover of your bike or frameset.

Our current lead time is between 60 – 90 Days. For a painted finish please add an additional 30 days.

We work with all the major Ride to Work schemes including:

Frame Buying Options

Handmade frames built to perfection by the Enigma team here in our Sussex workshop. Every Signature frame is meticulously crafted to exacting standards using the finest hand selected materials and is designed to deliver exceptional performance combined with an aesthetic that is classic, beautiful and ‘British’.

Our Signature Excel frame includes a satin bead finish with a choice of either mirror or anodised logos as standard. Please see our finishing page for more information.

    Frame Only Price:
  • Disc - £4070 | Rim - £3499
  • Price includes T47 Bottom Bracket & Internal Routing (Disc only)
  • Custom Geometry Upcharge + £300
    Frameset From Price:
  • Disc From - £4548 | Rim From - £3898

Disc model – Price includes our C-Six DSC Carbon Road Fork and TK036A Inset Headset, Titanium seat collar, thru-axles front and rear and any appropriate guides.

Upgrade Option – Add a Chris King Inset Headset & Enve Tapered Road Disc Fork for an extra £377

Rim - Price includes our C-Six RD-SL Carbon Road Fork and TK036A Inset Headset, Titanium seat collar and all small parts.

Upgrade Option – Add a Chris King Inset Headset & Enve Tapered Road Fork for an extra £247

Contact us for more details

Excel Ti64

Engineered from low density grade 5 6AL 4V titanium, harder than the more widely used 3AL 2.5V titanium, the Excel Ti64 exhibits outstanding characteristics. With a high strength-to-weight ratio combined with excellent fatigue and corrosion resistance, it’s a frame material that lends itself wonderfully to a premium build bicycle, where speed, smoothness and comfort combine in perfect harmony.

For all its undoubted benefits nothing comes easy with grade 5 6AL 4V titanium. The costs and difficulty of working with this remarkable material require all of our collective experience and knowhow as a team to harness its true potential. But once tamed, the result is a very special frame indeed. To further improve the Excel Ti64 for 2022, the frame now features 3D printed chain stay ends and disc brake mounts for additional strength and enhanced brake alignment accuracy. In addition, internal cable routing becomes standard along with the inclusion of a T47 bottom bracket shell, which not only allows for cable routing through the BB for a super-clean aesthetic but also increases lateral stiffness as well as ensuring an improved bearing interface. The Excel Ti64 delivers the ultimate titanium experience, not only in material quality but also frame finish, performance and bike handling.

Built to order and handcrafted to our highest standards, each Excel can be constructed to suit your specific riding conditions. Choose from Disc Road or Rim Brake Road and mechanical or electronic drive train configurations. House geometry with sizes in 1cm increments is standard and there is also the option of a full-custom frame design and build.

Enigma Customer - David Shaw

“Have had a couple of rides and the Excel handles like a dream, light and responsive. Even the hills are easier.”



Enigma Customer - Tiemen

“Bike really rides like a dream, performs good in the mountains and on the flat.”

Geometry

The sizing chart will help get you on the right size bike, please also refer to the geometry table for full specification. Learn more about Enigma Bike Sizing

Enigma Excel Ti64

Frame Size A - Top Tube (mm) B - Seat Tube (mm) C - Head Tube D - Chain Stay E - BB Drop F - Seat Angle G - Head Angle H - Fork Offset I - Stack J - Reach K - Wheel Base Down Tube OD Top Tube OD
50 500 470 95 420 75 76 71.5 47 515 369 980 42 32
51 510 485 105 420 75 75.5 71.5 47 529 371 985 42 32
52 520 500 115 420 75 75 72 47 539 374 383 42 32
53 530 515 125 420 75 74.5 72 47 548 377 992 44 35
54 540 530 135 420 75 74 72.5 47 559 380 993 44 35
55 550 545 145 420 75 73.5 72.5 47 568 382 999 44 35
56 560 560 155 420 75 73 73 47 580 383 999 44 35
57 570 575 165 420 75 73 73 47 589 391 1009 44 35
58 580 590 175 420 75 73 73 47 599 398 1019 44 35
59 590 605 185 420 75 72.5 73.5 47 610 399 1019 44 35
60 600 620 195 420 75 72.5 74 47 622 406 1023 44 35
Frame Size A - Top Tube (mm) B - Seat Tube (mm) C - Head Tube D - Chain Stay E - BB Drop F - Seat Angle G - Head Angle H - Fork Offset I - Stack J - Reach K - Wheel Base Down Tube OD Top Tube OD
50 500 450 105 415 75 76 71 47 522 366 971 42 32
51 510 465 115 415 75 75.5 71.5 47 531 370 978 42 32
52 520 480 125 415 75 75 71.5 47 541 373 984 42 32
53 530 495 135 415 75 74.5 72 47 552 375 985 44 35
54 540 510 145 415 75 74 72 47 564 377 991 44 35
55 550 525 155 415 75 73.5 72.5 47 573 380 992 44 35
56 560 540 165 415 75 73.5 72.5 47 582 387 1002 44 35
57 570 555 175 415 75 73.5 72.5 47 592 394 1012 44 35
58 580 570 185 415 75 73 73 47 603 396 1012 44 35
59 590 585 195 415 75 73 73 47 613 403 1022 44 35
60 600 600 205 415 75 73 73 47 622 410 1032 44 35

Sizing

Frame Size (Horizontal Top Tube)   Rider Height (cm) Rider Height (Inches) Saddle Height (mm)
50 158 5'2" 660
51 162 5'4" 680
52 166 5'5" 700
53 170 5'7" 720
54 174 5'8" 740
55 178 5'10" 760
56 182 6'0" 780
57 186 6'1" 800
58 190 6'3" 820
59 194 6'4" 840
60 198 6'6" 860

Our team of expert fitters are always on hand to help you choose, so if in any doubt please get in touch.
